093-7521 Spin-on Hydraulic Oil Filter CAT E312C E320C E320D Excavator

10
MOQ
$1-20
Price
093-7521 Spin-on Hydraulic Oil Filter CAT E312C E320C E320D Excavator
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: Spin On Hydraulic Oil Filter
Cross Reference: P551348,HF35081,BT305
Fit Equipment: CAT E312C,E320C,E320D,E320D2,E325D Excavator
Filter Media: High Efficiency Composite Filter Paper
Shell Material: Cold Rolled Steel Shell
Seal: NBR Nitrile Rubber Gasket
Thread Spec: 1 1/8-16 UN
Installation: Spin-on Direct Replacement
Application: Excavator Hydraulic Tank Filter,Construction & Mining
Package Size(D×H): 9×22cm
Net Weight: 0.72KG
Gross Weight: 0.83KG
HS Code: 8421290000
Highlight:

CAT excavator hydraulic oil filter

,

Spin-on hydraulic filter E312C E320C

,

Excavator engine air filter 093-7521
Basic Infomation
Place of Origin: CHINA
Certification: ISO9001
Model Number: 093-7521
Payment & Shipping Terms
Packaging Details: Neutral export carton
Delivery Time: 3-7 Works day
Payment Terms: T/T
Supply Ability: 50000/Years
Product Description

Product Description

093-7521 spin-on hydraulic filter serves as tank drain hydraulic filter for CAT series excavators, direct OEM replacement of original 093-7521 filter. Adopts high-density resin-impregnated filter media to intercept metal debris, sludge and fine impurities inside hydraulic oil, effectively protecting hydraulic pump, control valve and core hydraulic components from abrasion damage.

093-7521 Hydraulic Oil Filter for E312c E320c E320d Excavator
Attribute Details
Product Name 093-7521 Hydraulic Oil Filter For E312C E320C E320D Excavator
Part Number 093-7521, 0937521, 93-7521 (Old No.)
Filter Type Hydraulic / Transmission Oil Filter (Spin-on, High Efficiency)
Structure Spin-on Cartridge, Built-in Bypass Valve
Material High-Efficiency Glass Fiber Media, Steel Housing, Nitrile Seal
Filter Rating 10 μm (β10≥200, Efficiency ≥99.5%)
Overall Height 174.6 mm
Outer Diameter 93.7 mm
Thread Size 1 1/16-12 UNF-2B
Net Weight 0.95 kg
Gross Weight (Single) 1.05 kg
Single Package Size 105 * 105 * 185 mm
Packing 1 pc / neutral carton box
Application Engine/Machine Excavator: 311C, 312B/C/D, 314C, 318C, 320B/C/D, 323C/D, 325C/D, 330C/D, 336D, 345C/D; Skid Steer: 2290, 2390, 2490, 2590; Forestry: 538LL, 568LL
Cross Reference Fleetguard HF35018, P551348, Baldwin BT305, Wix 51621 / 57724, Luberfiner LFH8217
OEM Part No Cross Reference Fit Model
093-7521 P551348,HF35081 E312C,E320C,E320D,E325D
093-7522 P551349,HF35082 E330C,E330D,E336D
093-7523 P551350,HF35083 E307C,E308D,E311C
093-7524 P551351,HF35084 E345C,E349D Wheel Loader
093-7525 P551352,HF35085 E315C,E318D

Why choose us?

Certifications & Quality;

  • ISO 9001 certified.
  • 100% pressure, flow, and leakage tested before shipment to ensure quality.
  • Comply with construction machinery hydraulic component industry standards.
